Superb business processing concurrency capability

Using advanced network communication processors in the industry, combined with H3C's advanced software and hardware technology, we provide a wide range of concurrent business processing capabilities and network experiences

Firewall performance:
800Mbps

VPN encryption performance:
40Mbps

Number of NAT sessions: 250000

Support wireless 3G/4G wireless communication function

Wireless communication can be supported by connecting 3G/4G modems via USB interface, including CDMA 2000, WCDMA, TD-SCDMA, TDD-LTE, and FDD-LTE

Support the function of binding SIM/USIM cards to devices

Support multi factor binding authentication function under VPDN, achieving binding authentication of username/password/SIM card number/device serial number or MAC address

Support base station positioning function

Support SMS opening and abnormal alarm

WLAN wireless access and management

Supports 802.11n standard and is backward compatible with 802.11b/g

Support the built-in wireless AC controller function of the software, providing a solution for WLAN wireless coverage and management

Support rich WLAN encryption algorithms and secure authentication methods to ensure the security of wireless applications

Refined business control

By finely identifying and controlling, achieve functions such as speed limit, bandwidth guarantee, and filtering for application layer business, and guide network optimization through fine statistics

Business intelligent routing achieves full utilization of network links in different scenarios through technologies such as asymmetric link load sharing and traffic intelligent load sharing. It supports load sharing based on bandwidth ratio, user or user group, and business and application based load sharing

Support elastic sharing of network bandwidth based on multiple methods, including business based elastic sharing, user or user group based elastic sharing, link based elastic sharing, and user based bandwidth limitation

Zero configuration deployment

Batch device opening under zero configuration mode can be achieved

Zero configuration setup of devices can be achieved through wireless SMS

Automatic rollback of device configuration in case of misconfigured

Remote centralized management of devices behind dynamic addresses or NAT gateways

Embedded WiNet intelligent network management platform

Support automatic discovery and presentation of network topology for devices

Implement local user access authentication and network access control

Support device and link fault alarms

Full Chinese web interface, friendly and intuitive, easy and convenient to operate

Rich business control capabilities and network security prevention measures

Diversified firewall functions: support packet filtering firewall, stateful firewall, etc

Comprehensive built-in anti attack measures: supports various ARP anti attack, single packet attack, scan attack, and flood attack prevention measures, and supports traffic statistics to assist in attack prevention

Support URL filtering, black and white list function

Complete user behavior tracking records

Support endpoint admission defense function (EAD) based on wide area network

Refined business identification and control
