This product is an industrial grade 6-port full gigabit PoE switch.

This switch can provide 4 Gigabit Ethernet RJ-45 downstream ports, 1 Gigabit Ethernet RJ-45, and 1 Gigabit Ethernet SFP upstream port. All downstream RJ-45 Ethernet ports support Power over Ethernet (PoE++), and each port can provide up to 90W of power. The upstream RJ-45 Ethernet port supports up to 90W of PoE++power input.
Compliant with the IEEE802.3af/at/bt standard.

The switch supports Q-PoE (Quick PoE) technology, which immediately starts PoE power supply when the switch is started, without waiting for the switch system software to control it.

This switch supports two working modes: Default and CCTV.
In CCTV mode, the downstream port speed is reduced to 10M, and the maximum transmission distance is extended to 250 meters, which can be widely used in video security monitoring systems and network projects.

Rich interfaces

4*10/100/1000BASE-T PoE++ RJ-45 (Auto-MDI/MDI-X)

1*10/100/1000BASE-T RJ-45 (Auto-MDI/MDI-X)

(Supports up to 90W PoE++power input)

1*1000BASE-X SFP

1 * Relay port

High performance design

Redundant power supply design

Surge: 6kV

Static protection: 6kV contact discharge, 8kV air discharge

Fanless, metal shell design

Support rail mounted, desktop mounted, and wall mounted installation

Power over Ethernet (PoE++)

IEEE 802.3af/at/bt

90W PoE++power input

Single port maximum power 90W

Q-PoE (Fast PoE)

Support Q-PoE (Quick PoE) technology, immediately start PoE power supply when the switch is started, without waiting for switch system software control.

One click intelligence
